Machining
When it comes to counting on exactly what you called for, no one is more reliable than us.
machining Services
There are a fair number of major machining shops across the Midwest—we know, we’ve used a few of them ourselves—but when it comes to counting on exactly what you called for, no one is more reliable than us.
We take you from plate to paint—without outsourcing—because that gives us the kind of control you’d want if you were in our work boots. We oversee every step of the process; we understand your exact specifications; we make sure every part is perfect.
Machining Specs
Haas VF & CNC Vertical Machining Center
- Heavy Machining of Large Parts
- XYZ Axis Travels 84” x 32” x 30”
- 50 Taper Geared Head, 30hp, 7,500rpm
- 310mm, Full 4th Axis Rotary Table
Daewoo DMV 500 CNC Vertical Machining Center
- Medium-Duty Machining of Mid-Sized Parts
- XYZ Axis Travels 40.2” x 19.7” x 20.1”
- 40 Taper, 20hp, 10,000rpm
Daewoo DMC320 CNC Vertical Machining Center
- Rotating Dual Pallet for Efficient Small-Part Machining
- XYZ Axis Travels 20.4” x 12.5” x 11.8”
- 30 Taper, 10hp, 10,000rpm
Daewoo Puma 230 Turning Center
- High-Speed Accuracy for Medium and Light Parts
- Max Part Size: 13.8” Dia. x 21.1” Long
- 10” Chuck, Through Hole 3.03”
- 25hp, 3,500rpm, 12 Tool Stations
- LNS Bar Feeder and Programmable Tail Stock
Mazak Nexus QT 30 MY Turning Center
- Heavy Cutting of Large- to Medium-Sized Parts
- Max Part Size: 16.54” Dia. x 60.672” Long
- 12” Chuck, Through Hole 4.00”
- 40hp, 3,300rpm, 12 VDI Tool Station
- C-Axis .0001 Degree Increments; Y-Axis 5.9” Travel
- Live Rotary Tool Spindle Speed: 4,000rpm
- LNS Bar Feeder and Programmable Tail Stock
Production Workflow
We designed our fabrication workflow to minimize downtime, reduce rework, and move parts efficiently through production. Every process is documented, every weld is traceable, and every finished part is measured against your exact requirements.
